SW4 3G HD-SDI • Quick Start Guide
QS-3
Quick Start Guide — SW4 3G HD-SDI, cont’d
• If you are using auto-input switch mode, no action is necessary.
The switcher automatically switches to the highest numbered
active input.
N
Outputs 1 and 2 output an identical signal.
Step 3
If needed, you can create a remote connection via RS-232 (see
chapter 3, “Serial Communication”).
AUTO
SWITCH
ACTIVE
SW4 3G HD-SDI
MULTI-RATE SDI SWITCHER
1
MODE
2
NORMAL
3
AUTO
4
RATE
NOT
RECOGNIZED
270 Mbps
1.485 Gbps
2.97 Gbps
1
7
32
5
4
6
