• When connecting the RCP 2000 directly (no intermediate
device present, such as a network hub) to the ISS 108/408,
you must use a crossover cable. See the table on the next
page for RJ-45 crossover cable connections.
Pin Wire color
RJ-45 Ethernet Crossover Cable
Pin
1
White-orange
White-orange
Transmit + Receive +3
2
Orange OrangeTransmit - Receive -
6
3
White-green White-green
Receive + Transmit +
1
6 Green Green
Receive - Transmit -
N/A N/A
4
Blue Blue
5
White-blue White-blue
7
White-brown White-brown
8
Brown Brown
N/A N/A
N/A N/A
N/A N/A
Signal Signal
RCP 2000 end
Intermediate hub, etc., end
Wire color
2
4
5
7
8
• When connecting the RCP 2000 indirectly (intermediate
device present, such as a network hub) to the ISS 108/408,
you must use a patch (straight-through) cable. See the
table below for RJ-45 patch cable connections.
Pin Wire color
RJ-45 Ethernet Patch Cable
Pin
1
White-orange
White-orange
Transmit + Receive +1
2
Orange OrangeTransmit - Receive -
2
3
White-green White-green
Receive + Transmit +
3
4 Blue Blue
N/A N/A
N/A N/A
5
White-blue White-blue
6
Green Green
7
White-brown White-brown
8
Brown Brown
Receive - Transmit -
N/A N/A
N/A N/A
Signal Signal
RCP 2000 end
SGS 408, ISS 108/408 end
Wire color
4
5
6
7
8
