Programmer’s Guide, cont’d
Integration Scaling Matrix Switcher • Programmer’s Guide4-6
X
Dvz
X17
A front panel horizontal detail filter adjustment has occurred for the S-video or
composite video input tied to output
X
.
X17
is the filter variable.
1Blu
X19
The blue-only mode has been turned on or off from the front panel for one or both
outputs.
X19
is the on/off status for the either or both outputs. The leading “1” is
meaningless.
1Fil
X19
The edge enhancement mode has been turned on or off from the front panel for one
or both outputs.
X19
is the on/off status for the either or both outputs. The leading
“1” is meaningless.
RGB delay
X
Dly
X20
A front panel RGB delay adjustment has occurred.
X
is output number and
X20
is
the delay value, in 0.01 second steps.
X20
can be as much as 50 = 5.0 seconds.
Test pattern
Tst
X19
*
X21
A test pattern has been turned on or off from the front panel for one or both
outputs.
X19
is the on/off status for the two outputs and
X21
is the test pattern
selected.
Audio gain and attenuation
X
Aud
X22
A front panel audio input level adjustment has occurred.
X
is input number and
X22
is the audio gain or attenuation level.
Video and audio mute
X
Vmt
X
A front panel video mute operation has occurred.
X
is output number and
X
is
the mute status: 0 = off (video not muted), 1 = on (video muted).
X
Amt
X
A front panel audio mute operation has occurred.
X
is output number and
X
is
the mute status: 0 = off (audio not muted), 1 = on (audio muted).
PAL film mode
X
Flm
X
The PAL film mode has been selected or deselected from the front panel for the
selected input.
X
is input number and
X
is the on/off status for PAL film mode.
Automated adjustments
X
The Auto Image feature has been turned on or off from the front panel for all tie
creations.
X
is the on/off status.
