92 EPSON S1C63000 CORE CPU MANUAL
CHAPTER 4: INSTRUCTION SET
HALT Set CPU to HALT mode 2 cycles
Function: Halt
Sets the CPU to HALT status.
The CPU stops operating, thus the power consumption is reduced. Peripheral circuits such as
the oscillation circuit still operate.
An interrupt causes it to return from HALT status to the normal program execution status.
Code:
Mnemonic MSB LSB
HALT 11111111111001FFCH
Flags: EICZ
–––
INC [addr6] Increment location [addr6] 2 cycles
Function: [addr6] [addr6] + 1
(addr6 = 0000H–003FH)
Increments (+1) the content of the data memory addressed by the addr6.
Code:
Mnemonic MSB LSB
INC [addr6] 1000001a5a4a3a2a1a01040H–107FH
Flags: EICZ
↕↕
Mode: 6-bit absolute
Extended addressing: Invalid
