46
2 Connect the following three cables to the projector:
Video cable
•AC cable
Control cable
3 Flip the power switch to the on position (indicated by the symbol).
4 Connect the speaker cable to the connectors for the left and right speakers in the projector enclosure.
Match up the
R (right) and L (left) labels on the connectors.
Connect the Cables to the Subwoofer and AV Controller
1 Unpack the subwoofer from box #5.
2 Unpack the AV controller from box #1.
Video cable (HDMI port)
Control cable
(RS-232C port)
AC cable Power switch
Speaker connectors
