TRANSMITTER PROGRAMMING
Transmitter Programming: (Excludes RS-00 model without remotes)
Notes: Remote Transmitters/Transceivers come pre-programmed from the Factory. When re-learning remotes or adding
remotes, ALL your system’s remote codes must be learned at time of programming!! These systems allow storage of up
to 4 different remote codes in memory.
1. Turn key to the ON position. (Do not start vehicle) Pink wire must be connected!
2. Press Program/Valet button 4 times. Wait for the unit to flash the parking lights and/or honk horn exactly 4 times.
3. Press Lock Button #1 of the transmitter to be learned. You should get 2 light flashes and 2 horn honks indicating the
code has been learned. Now the unit is waiting for a 2
nd
code, so repeat this step as needed with up to 3 additional
remotes. The unit will flash the lights in succession after each code learned for up to 4 codes. (3 flashes after the 2
nd
code, 4 flashes after the 3
rd
code and 0 for 4
th
code.) If all 4 codes are learned, the unit will automatically exit code
learning mode, otherwise turn key OFF.
IGN
OFF
WAIT FOR
4 FLASHES
PRESS 4X's
FLASH 2, 3, or 4 X's
IGN
OFF
COMPLETE
PRESS LOCK
