1.6.4 Programmable key LEDs for MWI
There are new voice mails.
There is no new voice mail.
1.6.5 Power Indication LED (Power Light Enabled)
There is an incoming call.
1.6.6 Power Indication LED (Power Light Disabled)
There is an incoming call
2 Initial Connection and Setting
2.1 Connecting the phone
1. Connect to the network. Use the Ethernet cable in the package to connect the WAN port
on the back of your phone to an Ethernet port. The following two figures show
connection options.
a. Direct network connection—This method requires at least one available Ethernet port.
Connect the WAN port on the back of your phone to the Ethernet port. Since the phone
has a built-in router, it can be connected directly to the network.
b. Shared network connection—Use this method if you have a single Ethernet port which is
already in use. Disconnect the Ethernet cable from the Ethernet port and attach it to the
WAN port on the back of the phone. Then use the Ethernet cable in the package to
connect the LAN port on the back of the phone to the other device. The IP Phone now
shares a network connection.
