User data storage
Write to user data storage
ASCII ESC ‘ m a0 a1 a2 d1 ... dm
Hexadecimal 1B 27 m a0 a1 a2 d1 ... dm
Decimal 27 39 m a0 a1 a2 d1 ... dm
Value of m: 0 – 255
Writes m bytes of data to the user data storage ash page at the address specied. The printer waits for m bytes of data
following the 3-byte address, addr.
If any of the memory locations addressed by this command are not currently erased, the command is not executed.
Related information
Result of this write is returned in bit 2 of response to transmit status command 1D 72, n = 4.
Read from user data storage
ASCII ESC 4 m a0 a1 a2
Hexadecimal 1B 34 m a0 a1 a2
Decimal 27 52 m a0 a1 a2
Value of m: 0 – 255
Reads m bytes of data from the user data storage ash page at the address specied.
Read from non-volatile memory
ASCII ESC j k
Hexadecimal 1B 6A k
Decimal 27 106 k
Range of k: 20 – 63 (decimal)
Reads a two-byte word from location k in the history EEROM. The printer returns the word at the next available
opportunity.
Related information:
This is ignored in LEGACY emulation and the parameter byte goes into the print buffer.
Write to non-volatile memory (NVRAM)
ASCII ESC s n1 n2 k
Hexadecimal 1B 73 n1 n2 k
Decimal 27 115 n1 n2 k
Value of n1: 1
st
Byte
Value of n2: 2
nd
Byte
Range of k: 20 – 63 (decimal locations)
Writes the two-byte word, n1 n2, to location k in history EEROM.
Related information:
This is ignored in LEGACY emulation and the parameter bytes go into the print buffer.
