TA1501C Amplier
5
www.clarksynthesis.com
PRODUCT INTRODUCTION
OVERVIEW OF THE AMPLIFIER
The TA1501C amplier is the rst audio amplier designed exclusively for use with Clark Synthesis
transducers. This amplier incorporates the latest digital technology and provides features not available on
many ampliers. Please read this manual in its entirety so you can get the maximum enjoyment from your
Clark Synthesis product(s).
USING THIS AMPLIFIER WITH A CLARK SYNTHESIS TRANSDUCER
The TA1501C amplier works with all Clark Synthesis transducers. This manual outlines how to use this
amplier with our transducers.
CAUTION: This amplier is designed to provide power to one (1) transducer.
Please note, the TA1501C can provide more continuous power than the transducer can handle. Why do we
do this? Special effects audio signals often contain peaks that require extra power to be delivered to the
transducer. This amplier will supply those peaks without damaging the transducer, providing you, the user,
with a true Tactile Sound experience.
FEATURES
The Clark Synthesis TA1501C Amplier has the following features:
Class D design for powerful, clean sound•
All-metal cabinet•
Crisp, clean, and compact body design•
Built-in Crossover Control that enables control of the cutoff point from • 40 Hz to 400 Hz
Bypass control that disables the Crossover Control, allowing the amplier to reproduce full-frequency audio•
Front LED that indicates the amplier is connected to AC power•
• Auto/On saves power by turning the amplier stage on only when an audio signal is present
Powered • loop-through allows you to connect multiple ampliers together to a single audio source
Stereo inputs allow you to connect the amplier to multiple sources. The audio is automatically combined •
inside the amplier.
IEC-601 • Connector allows you to use a power cord other than the power cord supplied. This is especially
helpful if you live in a country that requires a different AC plug.
Amplier automatically runs on AC power from 100 to 240 VAC, 50/60 Hz•
The audio input section works with high-level and low-level line signals. This feature permits the amplier •
to work with studio-level and consumer-level audio signals
• 5-way binding posts for connecting the transducer wires
!
