3-20
Cisco MGX 8850 Routing Switch Command Reference
Release 2.0, Part Number 78-10467-04 Rev C0, October 2001
Chapter 3 Equipment and Resource Provisioning
addrscprtn
Syntax Description
Related Commands
cnfrscprtn, delrscprtn, dsprscprtns, dsprscprtn
Attributes
if_num Logical interface (port) number. For AXSM, the range is 1–60.
part_ID The number of the partition in the range 1–5.
ctrlr_id The number of the controller in the range 1–20.
egrminbw A guaranteed percentage of egress bandwidth. Each unit of egrMinBw is 0.00001 of the
total bandwidth on the port. (An egrMinBw of 1000000 = 100%.) This approach provides
a high level of granularity.
egrmaxbw A maximum percentage of the bandwidth. Each unit of egrMaxBw is 0.00001 of the total
bandwidth available to the port. (An egrMaxBw of 1000000 = 100%.) The resulting
bandwidth must be at least 50 cps.
ingminbw A guaranteed percentage of the ingress bandwidth. Each unit of ingMinBw is 0.00001 of
the total bandwidth available on a port. For example, an ingMinBw of 1000000 = 100%.
ingmaxbw A maximum percentage of the ingress bandwidth. Each increment of ingMaxBw is
0.00001 of the total bandwidth on the port. For example, an ingMaxBw of 1000000 =
100%. Note that the maximum ingress bandwidth must be at least 50 cps.
minVpi Minimum VPI. For NNI, the range is 0–4095. For UNI, the range is 0–255.
For a virtual trunk (VNNI interface type in the addport command), the minVpi must be
the same as the maxVpi.
maxVpi Maximum VPI in the range 0–4095 for an NNI. For a UNI, the range is 0–255. The
minVpi cannot be less than the maxVpi.
minVci Minimum VCI in the range 0–2000 (OC-48 only) or 32–65535.
maxVci Maximum VCI in the range 0–2000 (OC-48 only) or 32–65535.
minConns A guaranteed number of connections. The range is between 0 and the maximum number
of connections in the port group. See dspcd for information about port groups.
maxConns A maximum number of connections. The range is between 0 and the maximum number
of connections in the port group. See dspcd port group information. maxConns cannot be
less than minConns.
Log: log State: active Privilege: GROUP1
