REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
356700
K Included in Engine Gasket Set−Ref. No. 358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∆ Included in Valve Gasket Set−Ref. No. 1095A.
5360−18 Assemblies include all parts shown in frames. 10/26/2007
18
968 699959 Cover−Air Cleaner
(Used With Metal Air
Cleaner Base)
971A 807084 Screw
(Air Cleaner Base to
Carburetor)
975 807715 Bowl−Float
977 808325 Gasket Set−Carburetor
987
zD691548 Seal−Throttle Shaft
988 K692063 Gasket−Oil Adapter
996 691577 Shield−Carburetor
1004 842258 Duct−Air
(Used With Metal Air
Cleaner Base)
1005 841439 Fan−Flywheel
(Used After Code Date
04011800).
−−−−−− Note −−−−−−
809179 Fan−Flywheel
(Used Before Code
Date 04011900).
1006 690452 Retainer−Fan
1009 806474 Screw
(Starter Motor)
1017 690878 Screen−Oil Pump
1022 K∆806039 Gasket−Rocker Cover
1023 808648 Cover−Rocker
1023A 691558 Cover−Rocker
(Cylinder 1)
(With Fuel Pump)
1023B 691494 Cover−Rocker
1024 693186 Pump−Oil
1025 690689 Spool−Governor
1026 691836 Rod−Push
(Intake)(Steel)
−−−−−− Note −−−−−−
691758 Rod−Push
(Exhaust)(Aluminum)
1027 842921 Filter−Oil
1028 808235 Adapter−Oil Filter
1029 807323 Arm−Rocker
1036 Label−Emissions
(Available from a
Briggs & Stratton
Authorized Dealer)
1037 D807717 Ball−Choke Locator
1051 D690736 Ring−Retaining
1051A 691124 Ring−Retaining
1054 280275 Tie−Cable
1058 277107 Operator’s Manual
1090 691293 Retainer−Brush
1091 D691515 Cap−Limiter
1095A 808391 Gasket Set−Valve
1100 791959 Pivot−Rocker Arm
1119 691552 Screw
(Alternator)
1130 690746 Stud
(Intake Manifold)
1135 806497 Washer
(Crankcase
Cover/Sump)
1176 842067 Nut
(Exhaust Manifold)
1254 807084 Screw
(Rocker Cover Stud)
1319 794467 Label−Warning
1330 272144 Repair Manual
1392 690939 Nut
(Rewind Guard)
