PRO MIXER DJX750 User Manual
8
If the unit is damaged please do NOT return it to us, but
◊
notify your dealer and the shipping company immediately;
otherwise, claims for damage or replacement may not be
granted.
Always use the original box to prevent damage during stor-
◊
age or transport.
Make sure that children cannot play unsupervised with the
◊
unit or its packaging.
Online Registration
Please register your new BEHRINGER equipment right after
your purchase by visiting http://www.behringer.com and read
the terms and conditions of our warranty carefully.
Thank you for your cooperation!
Specications
Audio Inputs
Mic 40 dB Gain, XLR, electronically balanced input
stage
Phono in 40 dB Gain, unbalanced input
Line in 0 dB Gain, unbalanced inputs
CD in 0 dB Gain, unbalanced inputs
Return 0 dB Gain, unbalanced input
Audio Outputs
Master max. +21 dBu
Booth max. +21 dBu
Tape typ. 0 dBu
Send typ. 0 dBu
Phones Out max. 180 mW @ 75 W / 1% THD
Equalizer
Stereo Low +12 dB/-32 dB @ 50 Hz
Stereo Mid +12 dB/-32 dB @ 1.2 kHz
Stereo High +12 dB/-32 dB @ 10 kHz
Mic Low +15 dB/-15 dB @ 80 Hz
Mic Mid +15 dB/-15 dB @ 2.5 kHz
Mic High +15 dB/-15 dB @ 12 kHz
Kill Low -54 dB @ 50 Hz
Kill Mid -44 dB @ 1 kHz
Kill High -26 dB @ 10 kHz
Digital Eects Processor
DSP 24-bit Texas Instruments
A/D-D/A converter 24-bit Sigma-Delta, 64/128-times oversampling
Sampling rate 46.875 kHz
System specications
Signal-to-noise ratio > 80 dB (Line)
Crosstalk > 70 dB (Line)
Distortion (THD) < 0.03%
Frequency response 10 Hz - 55 kHz, +0/-3 dB
Power supply
Power consumption 32 W
Mains connection Standard IEC receptacle
Mains voltages/Fuses
100 - 120 V~, 50/60 Hz T 1 A H
220 - 230 V~, 50/60 Hz T 500 mA H
Dimensions/Weight
Dimensions (H x W x D) approx. 104.3 x 320 x 370.8 mm
approx. 4 ⁄" x 12 ⁄" x 14 3/5"
Weight approx. 3.9 kg
approx. (8 1/2 lbs)
BEHRINGER is constantly striving to maintain the highest
professional standards. As a result of these efforts, modications
may be made from time to time to existing products without
prior notice. Specications and appearance may differ from
those listed or illustrated.
