Safety Cont’d
…
IMPORTANT
To maintain accuracy of the meter, replace the discharged
battery immediately when the battery symbol appears on
the meter display.
Avoid measuring error from outside interference: keep the meter
away from spark plug or coil wires.
Avoid damaging the meter when testing voltage: disconnect the
test leads from the test points before changing functions.
Do not exceed the limits shown in the table below:
FUNCTION Terminal Input limit
DC Volts VHz
Ω
600 Volts DC
Frequency 500 Volts AC/DC
Ohm(resistance)
Diode
VHz
Ω
250 Volts AC/DC
DC 10A 10A *10A AC/DC
RPM
Duty Cycle(%)
Dwell angle
VHz
Ω
500 Volts AC/DC
★ 10 Amp measurement for 60 seconds maximum.
① Ohms can not be measured if voltage is present, ohms can be
measured only in a non-powered circuit. However, the meter is
protected to 250 volts
Meter Basics
1. Display:
Large 3 1/2 digit (1999 counts) LCD display with low battery
indication.
2. Rotary Selector Switch:
Turn this switch to Select a function or turn the meter OFF.
3. Test Lead Terminals:
The Black test is used in the common(COM) terminal for all
rests. The Red test Lead is used to measure Amp or Volts.
