5-27
SERVICE AND APPEARANCE CARE
85Z04-03E
7) Replace the lamp housing into the vehi-
cle using the two screws removed ear-
lier.
8) Close the lift gate.
License Plate Lamps
To replace a license plate lamp bulb:
1) Remove the two screws shown in the
illustration and the lamp cover.
2) To remove the bulb holder from the
lamp housing, rotate the bulb holder
counterclockwise.
3) Pull the bulb out from the bulb holder.
4) Replace the bulb. See “Replacement
Bulbs” in this section for the proper
bulb.
5) Install the bulb holder into the lamp
housing by rotating the bulb holder
clockwise.
6) Replace the lamp cover.
Rear Side marker Lamps
To replace a rear side marker lamp bulb:
1) Insert your hand into the inside of the
rear bumper and hold the socket.
2) Rotate the rear side marker bulb socket
counterclockwise.
3) Pull the rear side marker bulb socket
out of the rear bumper.
4) Pull the old bulb straight out from the
bulb socket.
5) Push a new bulb straight into the
socket.
6) Reverse the steps 1 through 3 to rein-
stall the bulb socket.
Replacement Bulbs
N4U5029B
Bulb
Wattages
x
Quantity
Bulb
No.
High-Beam
Headlamp
55W x 2 H1
Low-Beam
Headlamp
55W x 2 H7
Front Turn Signal
Lamp
28/8W x 2 2357NA
Front Sidemarker
Lamp
5W x 2 168
Stop Lamp/
Tail Lamp
27/8W x 4 1157
Rear Turn Signal
Lamp
27W x 2 1156NA
Backup Lamp 27W x 2 1156
License Plate
Lamp
5W x 2 168
Center
High-Mounted
Stop Lamp
5W x 5 168
Rear Sidemarker
Lamp
5W x 2 168
