ASSEMBLY AND SET-UP
Charging the Battery
Your Pocket Mod may not have a fully charged battery; therefore it is a good idea to charge the battery prior to use.
• Initial charge time: 12 hours • Run time: up to 40 minutes
• Recharge time: up to 8 hours • Average battery life: 250 charge/discharge cycles
depending on the level of depletion
1 Plug the charger port into
the port on the Pocket Mod. The
charger works with the power
switch in either the on or off
position.
2 Plug the charger plug into a wall
outlet.
WARNING:
Rechargeable batteries are only to
be charged under adult supervision.
Always disconnect your Pocket Mod
from the charger before cleaning
with liquid.
Note: If your charger does not
look like the one illustrated,
your unit has been supplied
with an alternative charger.
The specifications and charging
procedure would not change.
The charger has a small window
with one LED or two LEDs to
indicate the charge status. Refer
to the illustration on the charger
unit for the actual “charging” and
“charged” status indications for
your model charger.
Chargers have built-in over-charge
protection to prevent battery from
being over-charged.
Be sure to properly align the
groove on the charger input
plug with the corresponding
socket on the case; otherwise,
no charging action will occur.
Charger
Plug
Charger
Port
WARNING: Failing to
properly adjust and tighten the
clamps and retainers that affix the
handlebar can cause you to lose
control and fall.
1 Insert handlebar assembly
through front fairing and into
fork until it stops. Raise to
desired height keeping the stem
and fairing aligned within the
red arrows of the safety zone.
2 Tighten down the hexagonal
bolt with the 5mm hexagonal key
wrench.
Attaching the Handlebars
1 Remove the packing material
from the front fork.
2 Insert the wheel into the front
fork with the lock washers on the
outside of the fork.
Attaching the Front Wheel
3 Insert the tab on the lock
washer into the hole on the front
fork and tighten the nuts with the
supplied wrenches.
