HOW TO READ THE KINETIC WAVE
DISPLAY
The kinetic wave display shows the signal receiving status of the
main unit. There are three possible forms:
The unit is in searching mode.
Transmission data are securely
registered.
No signal received in search mode.
REMOTE SENSOR SCANNING
The unit can be set to automatically scan and display readings from
the remote sensors and indoor readings. When the remote-sensor
mode is active, the display will show the readings from one channel
for about 4-second and then proceed to the next channel display.
To activate the remote-sensor scanning mode:
Press and hold [CHANNEL] for 2-seconds.
To deactivate the remote-sensor scanning mode:
Press either [CHANNEL], [MEM], [HI/LO], [
], [ ON / OFF]
(TEMP % RH AL)
THE COMFORT-LEVEL ICONS
The comfort level indicators COM, WET or DRY will tell you if the
current environment is comfortable, too wet or too dry.
The comfort indicator will appear on the display when the follow-
ing conditions are satisfied:
Indicator
displays
on the unit
COM
WET
Temperature
Range
20°C to 25°C
(68°F to 77°F)
-5°C -+ 50°C
(23°F - 122°F)
-5°C -+ 50°C
(23°F - 122°F)
Humidity
Range
40%RH-
70%RH
OVER-
70%RH
Below
70%RH
Shows that the
Current
Environment
Ideal range for
both relative
humidity and
temperature
Contains excess
moisture.
Contains
inadequate
moisture
No
Indicator
Less than
20°C( 68°F)
or More than
25°C (77°F)
40%RH
to
70%RH
No comment
DRY
