LT12D50SA LIGHT TOWER • PARTS MANUAL — REV. #1 (06/03/11) — PAGE 31
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 29676 FUEL TANK ASSY. ................................................................ 1 ............... INCLUDES ITEMS W/#
2# 29605 FUEL TANK 1
3# 29694 CAP, FUEL TANK W/LANYARD 1
4 29674 STRAP, FUEL TANK 1
5# 19633 BUSHING, FUEL 3
6# 12006 FITTING, 90° 1
7# 29677 FITTING, 90° ........................................................................1 ............... S/N 904605 AND BELOW
7# 20795 VALVE, SHUTOFF 4MBARB X 6SBARB SCREEN ............. 1 ............... S/N 904306 AND ABOVE
8# 19661 VALVE, SHUTOFF 5BARB X 6SBARB NO SCREEN 1
9 0447 WASHER, FLAT 2
10 10176 NUT, NYLOCK 1/2-13 2
11 22066 CLAMP, STEPLESS EAR 3/16 HOSE #123 4
12 60028 HOSE, FUEL RETURN .312 ID SAE J30R7 AR 1PC = 1 FT.
13 60004 HOSE, FUEL LINE .187 I.D. SAE J30R7 AR 1PC = 1 FT.
