127
Controls in detail
Lighting
Switching on front fog lamps
̈ Make sure the low beam headlamps
are switched on.
̈ Pull out exterior lamp switch to first
stop.
The green indicator lamp ‡ in the
lamp switch comes on.
Switching on rear fog lamps
̈ Make sure the low beam headlamps
are switched on.
̈ Pull out exterior lamp switch to second
stop.
The yellow indicator lamp † in the
lamp switch comes on.
Combination switch
The combination switch is located on the
left side of the steering column.
1 High beam
2 High beam flasher
Switching on high beams
̈ Turn exterior lamp switch to
position B (
୴ page 124).
̈ Push the combination switch in
direction 1.
The high beam indicator A on the
instrument cluster is illuminated
(
୴ page 22).
i
Fog lamps will operate with the parking
lamps and/or the low beam head-
lamps on. Fog lamps should only be
used in conjunction with low beam
headlamps. Consult your State or Prov-
ince Motor Vehicle Regulations regard-
ing allowable lamp operation.
i
The front fog lamps and rear fog lamp
cannot be switched on manually with
exterior lamp switch in position U.
To activate the fog lamps, turn exterior
lamp switch to position B and pull
the exterior lamp switch to first or sec-
ond stop (
୴ page 124).
