The fuses are coded as follows:
Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse Panel
Description
1 5A Instrument panel dimmer switch
2 10A Trailer tow park lamps
3 10A Right low beam headlamp
4 10A Left low beam headlamp
5 5A Windshield wiper module (RUN/ACCY)
6 10A Radio (RUN/ACCY), Door switch
illumination
7 5A Not used (spare)
8 10A Restraints Control Module (RCM), PADI
(Passenger Air bag Deactivation
Indicator), Occupant Classification
Sensor (OCS)
9 5A Cluster air bag indicator
2008 B-Series (mbs)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
171
