RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg35584
COOLER MNT 3025316-349D1.
HHCS 5/16-18X3/4 GR5802-007C2.
HHCS 3/8-16X2 GR5802-143C3.
NUT HEX 5/16-18 PLT803-008C4.
NUT HEX 3/8-16 PLT803-014C5.
WASHER LOCK SPRING 5/16 PLT804-009C6.
WASHER FLAT 3/8 SAE PLT804-012C7.
WASHER LOCK SPRING 3/8 PLT804-013C8.
WASHER FLAT 5/16 SAE PLT804-036C9.
OIL COOLER 3025810-703C10.
SWITCHBOX AND HARNESS HRS823-361C11.
VALVE MANUAL 3000 PSI 30GPM829-138C12.
EL 1 5/16MORB 1 5/16MJIC841-609C13.
HH1R17 40 1 5/16FJIC841-963C14.
HH1R17 21 1 5/16FJIC/MORB841-964C15.
HH1R17 34 1 5/16FJIC841-965C16.
AD 1 1/6MORB 1 5/16MJIC851-067C17.
EL 45 1 1/16MORB 1 5/16MJIC851-069C18.
08/12/15 HRS3025 Hydraulic Reservoir System 316-271P 41
Table of Contents Part Number Index
Section 6: Options & Accessories Land Pride
Manual Valve Option W/Cooler S/N 813091+
Applies to HRS3025
