113674_0711 7-17
60" Deck Pulleys & Spindles
NOTES:
1. Torque to 67-75 ft-lbs.
INDEX NO. PART NO. QTY. DESCRIPTION
1 794446 1 CS .625-11 X 1.500 HX G5
2 028118 2 FW .625 X 1.00 X .134 ZNYC
3 603057 2 DUST SHIELD WITH OFFSET
4 781385 2 IDLER PULLEY, NHI 6.0"
5 600296 2 DECK IDLER SPACER
6 373191 1 CHAIN
7 781302 1 TENSION SPRING
8 350884 1 DECK IDLER SLIDE
9 603023 4 WN .312-18 ZN
10 602936 2 UHMW IDLER SLIDE
11 705954 15 CS .500-13 X 1.250 HX G5 ZN
12 752386 3 CW .515 X 2.25 X .204 BLK
13 770842 3 DECK DRIVE PULLEY
14 045765 3 FW 1.030 X 1.500 X .134 ZN
15 016972 2 NT .625-11 HX G5 ZNYC
16 602963 1 IDLER DUST SHIELD LG
17 602743 1 IDLER, 10.0" RIVETED
18 767954 6 FW .406 X .812 X .060 SAE
19 086660 6 NT .375-16 HXZY NL
20 015495 2 GREASE FITTING STRAIGHT
21 113340 1 PUSHER
22 767962 15 FW .531 X 1.063 X .090 SAE
23 601630 3 BLADE SPINDLE
24 212472 3 KEY 1/4 SQ X 1.00
25 782474 2 CW .631 X 2.250 X .187 PNT
26 783738 2 CS .625-11 X 3.00 FULL HX
27 603022 4 CS .312-18 X .625 BH ZN
28 603113 6 CB .375-13 X 1.250 G5 ZN
29 602338 1 CB .50-13 X 7.50 STD ZN
30 602341 1 ANTI-SCALP WHEEL
31 602344 1 ANTI-SCALP SPACER 5.73
32 781567 3 NT .500-13 HX G8 ZY NL
33 602263 2 SIDE ANTI-SCALP WHEEL
34 602345 2 ANTI-SCALP SPACER 3.22
35 603049 2 CB .500-13 X 5.00 ZNYC
