SKU 94830 For technical questions, please call 1-800-444-3353 PAGE 9
PARTS LIST AND ASSEMBLY DIAGRAM
NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
1
2
3
4
5
5
5
5
6
6
6
7
7
7
6
7
8
8
10
10
10
10
9
9
11
12: Bolt not shown.
13: Washer not shown.
14: Nut not shown.
Part Description Qty.
1 Side Extension (Right) 1
2 Side Extension (Left) 1
3 Ramp Extension (Right) 1
4 Ramp Extension (Left) 1
5 Bolt 4
6 Washer 4
7 Nut 4
Part Description Qty.
8 Extension Panel Pipe 2
9 Pipe Cap 2
10 Pin 4
11 Stabilizer Bar 1
12 Bolt 4
13 Washer 4
14 Nut 4
