32
Starting the demonstration display
The demonstration display checks the controls on the display unit
and conducts a loopback test between the display unit and the
transceiver unit.
1.
Press / to select DEMONSTRATION.
2.
Press to select ON.
3.
Press the EVENT key.
The echo display appears and the demonstration begins. "DEMO
DATA OUTPUTTING” appears while the demonstration display is on.
All data shown is for purpose of demonstration; it is not actual data.
To quit the demonstration display, select “DEMONSTRATION-
OFF” on the MODE menu and press the EVENT key.
Figure 33 MODE menu
MODE
CALB
SELF TEST
OFF SYS
OFF ON
T/D NAV
SPD L/L
ECHO PNL
DEMONSTRATION
WATER SPEED
NAV DATA *1
*1: Shown when tide
processor is active.
*1
