Retain the original transmitter for use in other vehicles as well as for
future programming procedures (i.e. new HomeLink equipped vehicle
purchase). It is also suggested that upon the sale of the vehicle, the
programmed Homelink Universal Transceiver buttons be erased for
security purposes, refer to Programming in this section.
Programming
Do not program the HomeLink Universal Transceiver with the
vehicle parked in the garage.
Note: Your vehicle may require the ignition switch to be turned to the
ACC position for programming and/or operation of the HomeLink.Itis
also recommended that a new battery be placed in the hand-held
transmitter of the device being programmed to HomeLink for quicker
training and accurate transmission of the radio-frequency signal.
1. Press and hold the two outside
buttons releasing only when the red
light begins to flash after 20
seconds. Do not repeat step one to
program additional hand-held
transmitters to the remaining two
HomeLink buttons. This will erase
previously programmed hand-held
transmitter signals into HomeLink.
2. Position the end of your hand-held transmitter 2–8cm(1–3 inches)
away from the HomeLink Universal Transceiver surface (located on
your visor) while keeping the red light in view.
3. Simultaneously press and hold
both the HomeLink and hand-held
transmitter button. Do not release
the buttons until step 4 has been
completed.
Some entry gates and garage door
openers may require you to replace
step 3 with procedures noted in the
“Gate Operator and Canadian Programming” section for Canadian
residents.
4. The red light will flash slowly and then rapidly. Release both buttons
when the red light flashes rapidly. (The rapid flashing light indicates
acceptance of the hand-held transmitters’ radio frequency signals.)
5. Press and hold the just-trained HomeLink button and observe the red
light. If the light is a constant red, programming is complete and your
REC DEL PLAY
REC DEL PLAY
Driver Controls
90
