Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
BTN 40A* Hazard, Stop, Door Lock, Tail, Room and
Horn Fuses of the I/P Fuse Panel
ABS 60A* ABS Main Relay
COOLING
FAN
40A* Constant Control Relay Module (Cooling
Fan)
OBD-II 10A* Data Link Connector (DLC), Instrument
Cluster
FUEL
PUMP
20A** Constant Control Relay Module (Fuel
Pump)
HEAD RH 10A** Headlamps
HEAD LH 10A** Headlamps
* Fuse Link Cartridge **Fuse
Sedan
USE THE DESIGNATED FUSES ONLY
FUEL INJ
30A
DEFOG
30A
MAIN
100A
COOLING FAN
40A
(ABS)
60A
BTN
40A
HEADLAMP
RELAY
FUEL PUMP 20A
OBD-II 10A
HEAD RH 10AHEAD LH 10A
Roadside emergencies
114
