Trailer Towing Table
GCWR (Gross Combined Weight Rating)/Trailer Weights
Engine
Rear
axle
ratio
Maximum
GCWR-kg
(lbs.)
Trailer weight
range-kg (lbs.)
(0-Maximum)
Maximum
Frontal Area Of
Trailer-m
2
(ft
2
)
Club Wagon Regular E-350 (12 passenger)
5.4L 3.55 5 443 (12 000) 2 722 (6 000) 5.52 (60)
5.4L 4.10 5 897 (13 000) 3 175 (7 000) 5.52 (60)
6.8L 3.73 6 804 (15 000) 4 037 (8 900) 5.52 (60)
6.8L 4.10 8 392 (18 500) 4 536 (10 000) 5.52 (60)
Club Wagon Super E-350 (15 passenger)
5.4L 3.55 5 443 (12 000) 2 586 (5 700) 5.52 (60)
5.4L 4.10 5 897 (13 000) 3 039 (6 700) 5.52 (60)
6.8L 3.73 6 804 (15 000) 3 901 (8 600) 5.52 (60)
6.8L 4.10 8 392 (18 500) 4 536 (10 000) 5.52 (60)
E-350 Cutaway (dual rear wheel)
5.4L 4.10 5 897 (13 000) a* 5.52 (60)
6.8L 4.10 8 392 (18 500) a* 5.52 (60)
E-450 Cutaway (dual rear wheel)
6.8L 4.63 9 072 (20 000) a* 5.52 (60)
E-250/350 Stripped Chassis
(single rear wheel-124؆wheelbase for E-250 only)
4.2L 4.09 4 990 (11 000) 1 090 (2 400) 5.52 (60)
5.4L 4.10 5 897 (13 000) 1 542 (3 400) 5.52 (60)
E-350 Stripped Chassis (dual rear wheel)
5.4L 4.10 5 897 (13 000) 1 361 (3 000) 5.52 (60)
a* Maximum trailer weight for all cutaway (E-350 and E-450) vehicles must be
calculated by subtracting the weight of the vehicle (including incomplete vehicle weight,
and payload which includes second unit body weight, cargo, and passengers) from the
GCW. Otherwise, maximum trailer weight is 4 536 kg (10 000 lbs).
b* Maximum loaded trailer weight of 4 717 kg (10 400 lbs.) on 7.3L E350 cutaways
(single rear wheel) applicable to fifth wheel trailer usage only. Otherwise, maximum
trailer weight is 4 536 kg (10 000 lbs.).
For high altitude operation reduce GCWR by 2% per 300 meters (1 000 ft) elevation.
To determine the maximum trailer weight designed for you particular vehicle as equipped,
follow the section Calculating the load your vehicle can tow/carry earlier in this chapter.
Driving
122
