driveshaft and axle flanges to ensure proper position when
reconnecting the driveshaft. Refer to the “Workshop Manual” for
proper fastener torque specifications.
When disconnecting/installing the driveshaft, the parking brake
must be set and the wheels blocked to ensure the vehicle does
not roll.
• When the driveshaft is disconnected, the maximum speed is 88 km/h
(55 mph) and the distance is unlimited.
• If you must exceed the distance or 80 km (50 miles) and/or speed of
56 km/h (35 mph), you must remove the rear driveshaft. Mark the
driveshaft and axle flanges to ensure proper position when
reconnecting the driveshaft. Refer to the “Workshop Manual” for
proper fastener torque specifications.
For manual transmissions, maximum speed is 88 km/h (55 mph) and
distance is unlimited.
Limited vehicle operation, such as driving the vehicle at a campsite, can
be accomplished with the rear driveshaft removed by using the front
drive to propel the vehicle. To operate the vehicle in this condition, you
must follow these guidelines:
• Place the transfer case in 4WD by rotating the 4WD control to 4WD
HIGH.
• Drive the vehicle only on good surface roads to avoid excessive loads
on the front-wheel drive system.
• Maximum speed is 56 km/h (35 mph).
• Maximum distance is 80 km (50 miles).
• Avoid quick acceleration and steep grades.
To return the vehicle to a towable condition, you must place the transfer
case in 2WD by rotating the 4WD control to 2WD. Both the 4WD HIGH
and 4WD LOW indicator lights in the instrument cluster will be off when
the 4WD control is in 2WD.
In addition, it is recommended that you follow the instruction provided
by the manufacturer of the towing apparatus.
Driving
91
