If the battery has been disconnected and reconnected, refer to the
Battery section of the Maintenance and Care chapter.
The high-current fuses are coded as follows.
Fuse/Relay
Location
Fuse Amp
Rating
Description
1 25A * Power Point
2 30A* Powertrain Control Module
3 30A* Headlamps/Autolamps
4 25A* Console Powerpoint
5 20A* Trailer Tow Backup/Park Lamps
6 15A* Parklamps/Autolamps
7 20A* Horn
8 30A* Power Door Locks
9 15A* Daytime Running Lamps (DRL), Fog Lamps
10 20A* Fuel Pump
11 20A* Alternator Field
MAXI
FUSE
115
MAXI
FUSE
116
MAXI
FUSE
117
MAXI
FUSE
118
MAXI
FUSE
111
MAXI
FUSE
112
MAXI
FUSE
113
MAXI
FUSE
114
MAXI
FUSE
107
MAXI
FUSE
108
MAXI
FUSE
109
MAXI
FUSE
110
MAXI
FUSE
103
MAXI
FUSE
104
MAXI
FUSE
105
MAXI
FUSE
106
MAXI
FUSE
101
MAXI
FUSE
102
CB601 CB602
FUSE 17 FUSE 18
FUSE 21 FUSE 22
FUSE 19 FUSE 20
FUSE 23
FULL
RELAY 302
R 401
D 501
FUSE 24
FUSE 15 FUSE 16
FUSE 13 FUSE 14
FUSE 11 FUSE 12
FUSE 9 FUSE 10
FUSE 7 FUSE 8
FUSE 5 FUSE 6
FUSE 3 FUSE 4
FUSE 1 FUSE 2
D 503
D 502
FULL
RELAY 301
HALF
RELAY
207
FULL
RELAY 303
FULL
RELAY 304
HALF
RELAY
201
HALF
RELAY
202
HALF
RELAY 208
HALF
RELAY 209
HALF
RELAY 205
HALF
RELAY 206
HALF
RELAY
203
HALF
RELAY
204
HALF
RELAY
212
HALF
RELAY
210
HALF
RELAY
213
HALF
RELAY
211
