Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
39 10 Amp
Red
Heated Mirrors - if
equipped
40 5 Amp
Orange
Auto Inside Rearview
Mirror/Heated Seats - if
equipped/Switch Bank
41———
42 30 Amp
Pink
Front Blower Motor
43 30 Amp
Pink
Rear Window Defroster
44 20 Amp
Blue
Amplifier/Sunroof - if
equipped
* Cavities 11, 12, and 13 contain self-resetting fuses
(circuit breakers) that are only serviceable by an autho-
rized dealer. The cluster and the driver seat switch are
fused by the 25 Amp circuit breaker in cavity 11. The
passenger seat switch is fused by the 25 Amp circuit
breaker in cavity 12. The door modules, the driver power
window switch, and the passenger power window
switch are fused by the 25 Amp circuit breaker in cavity
13. If you experience temporary or permanent loss of
these systems, see your authorized dealer for service.
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than
21 days, you may want to take these steps to protect your
battery.
Disconnect the negative cable from the battery.
Anytime you store your vehicle, or keep it out of
service (i.e., vacation) for two weeks or more, run the
air conditioning system at idle for about five minutes
in the fresh air and high blower setting. This will
ensure adequate system lubrication to minimize the
possibility of compressor damage when the system is
started again.
