17
OPTIONS PROGRAMMING
To Engage Option Programming:
1. Open hood (If no hood pin switch is installed, then ground the Gray wire)
2. Turn Key to the ON position. (Do not start vehicle) Pink wire must be connected!
3. Press the program / valet button 5 times. Wait for the unit to flash the lights and/or horn honk 5 times.
4. Push the valet/program button the number of times that corresponds to the option number desired (1-22X). You
must get a light flash and/or honk after each button press. If the system did not flash the lights and/or honk, then
it did not register your press. Press carefully and do not lose count.
5. A) For EZ-30DP/31DP/33DP/34DP or 64TW1/74TW2/84FM: When you reach the desired option #, Press
button #1(Lock) or #2 (Unlock) to change the option. (Some option numbers use ALL 4 remote buttons to select
settings)
5. B) For EZ-30DP: (No remotes) Tap the brake pedal to toggle through the option values: Tap the brake once
(lights flash 1X; Tap the brake pedal again (Lights flash 2X) tap 3 or 4 times for options that have 3 or 4 values.
6. When finished, turn Ignition OFF, close hood (or un-ground Gray wire) and check for changed features.
* = Default Value
Option # Option Description Option Values Button #1
LOCK
Button #2
UNLOCK
1. Engine Monitoring Tach (Engine RPM) or Tachless Tach Tachless*
2. Autolock with RPM/Ignition ON or OFF. ON *OFF
3. Door Lock Pulse Time 0.75 Sec. (Standard) OR
3.0 Sec. (European Vacuum)
3 Sec. *0.75 Sec.
4. Double Unlock Pulse Single or Double Unlock Pulse Double *Single
5. OEM Interface
(EZ-30 MODEL ONLY)
Remote Start w/Single Pulse or 3
Pulses on Green input wire
3 pulse *1 Pulse
6.
Double button press for remote
start and Trunk release
ON or OFF ON *OFF
7. Horn Chirps on remote start ON or OFF ON *OFF
8. Lock During and After
Remote Start Abort
ON or OFF OFF *ON
9. Tan Wire Output function Trunk or Dome Light Output Dome *Trunk
10. “Wake up” Pulse on Unlock
(1-sec +12V to IGN)
ON or OFF ON *OFF
