GPSL Status
The GPS icon changes to indicate received signal status:
NOTE
When GPS signal is lost at the Speed and Lat/Lon screens, the satellite icon
will change and the data lines will be filled with dashes.
Initial Satellite Lock
•
When the Optional GPSL is first used or after a prolonged period of nonuse,
the GPSL needs more time to detect the Global Position System satellites.
1. After installation of the GPSL, turn the detector unit On with the vehicle in
an area clear of obstructions to the sky.
2. Keep the detector turned On for at least 15 minutes to allow fast satellite
acquisition in subsequent power-ups. The vehicle can be moving as long
as it is in an area where the GPSL can “see the sky.”
Optional Global Position System
Locator (GPSL)
Optional GPSL
Optional Global Position System
Locator (GPSL)
Optional GPSL
36
English
n
To set a User Location: Press and hold the Menu/Save button for at least two
seconds when the vehicle is at a location you want to save.
n
To delete a specific User Location: Press and hold the Menu/Save button for
at least two seconds while at that location and the User Location Alert is
sounding. A specific location can be deleted only while at that location.
n
To delete all User Locations: When an Optional GPSL unit is installed, you can
delete all user-entered Location Alerts in Menu mode (see page 15).
Speed Alert
When a GPSL unit is installed and receiving a signal and Speed Alert mode
is turned On, the detector will sound an alert whenever the vehicle's speed exceeds
the set point you have selected. The speed settings can be adjusted
in 5 mph or km/h increments. The factory setting is Speed Alert Off. Speed
units can be selected as a User setting.
Compass
When a GPSL unit is installed and receiving a signal, you can see your direction of
travel based on the GPS system. The GPS compass overrides
the magnetic compass.
GPS Database Information
When a GPSL unit is installed, you can view the date on which the installed database
of Photo Enforcement Locations was updated. To update the database,
go to Cobra's website (www.cobra.com) and follow the online instructions.
GPSL Activated Alerts
•
In addition to the alerts provided by the detector, the GPSL provides alerts based on
vehicle location and information in the GPSL databases.
Photo Enforcement Alerts
Whenever your vehicle approaches a photo enforced location contained in the built-
in GPSL database, an alarm will be provided with a unique chime and the camera
icon will become progressively larger as you approach the location.
User Location Alerts
The system can store up to 1,000 User Location Alerts to provide warnings at
locations not included in the built-in GPSL database. Whenever your vehicle
approaches a user set location, an alarm will be provided with a unique chime and
the flag icon will become progressively larger as you approach the location.
Nothing Comes Close to a Cobra
®
37
Photo Enforcement Alert Signal
Zone 1 Zone 2 Zone 3
Icon size increases as
location is approached.
Icon size increases as
location is approached.
User Location Alert Signal
Zone 1 Zone 2 Zone 3
