Cav-
ity
Cartridge
Fuse
Mini-Fuse Description
17 20 Amp
Yellow
Rear Fog Lamps (Ex-
port Only)
18 20 Amp
Yellow
Front Control Module
(FCM) Batt #1
19 20 Amp
Yellow
Lt Trailer-Tow Stop/
Turn
20 20 Amp
Yellow
Front Control Module
(FCM) Batt #3
21 20 Amp
Yellow
Rt Trailer-Tow Stop/
Turn
22 30 Amp
Pink
Final Drive Control
Module (FDCM)
MOD
23 50 Amp
Red
Radiator Fan
27 15 Amp
Blue
Ignition Off Draw
(IOD) #1
Cav-
ity
Cartridge
Fuse
Mini-Fuse Description
28 20 Amp
Yellow
Ignition Off Draw
(IOD) #2
29 10 Amp
Red
Occupant Restraint
Controller (ORC) R/S
30 10 Amp
Red
Occupant Restraint
Controller (ORC) R/O
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than
21 days you may want to take steps to protect your
battery. You may:
•
Remove fuse #27 in the Intelligent Power Module
labeled Ignition-Off Draw (IOD#1).
•
Or, disconnect the negative cable from the battery.
•
Anytime you store your vehicle, or keep it out of
service (i.e. vacation) for two weeks or more, run the
