Chevrolet 2009 Malibu Automobile User Manual



Fuses Usage
8 Horn
9 Right Headlamp Low-Beam
10 Front Fog Lamps
11 Left Headlamp High-Beam
12 Right Headlamp High-Beam
13
Engine Control Module BATT
(LY7 & LE5)
14 Windshield Wiper
15 Antilock Brake System (IGN 1)
16
Engine Control Module IGN 1
(LY7 & LE5)
17 Cooling Fan 1
18 Cooling Fan 2
19
Run Relay, Heating, Ventilation,
Air Conditioning Blower
20 Body Control Module 1
21 Body Control Module Run/Crank
22 Rear Electrical Center 1
23 Rear Electrical Center 2
24 Antilock Brake System
Fuses Usage
25 Body Control Module 2
26 Starter
41 Electric Power Steering
42
Transmission Control Module
Battery
43
Ignition Module (LZ4, LZE & LE5);
Injectors, Ignition Coils Odd (LY7)
44
Injectors (LZ4, LZE & LE5);
Injectors, Ignition Coils Even (LY7)
45
Post Cat 02 Sensor Heaters
(LY7, LZ4 & LZE)
46 Daytime Running Lamps
47 Center High-Mounted Stoplamp
50 Driver Power Window
51
Engine Control Module BATT
(LZ4 & LZE)
52 AIR Solenoid
54 Regulated Voltage Control
55 DC/AC Inverter
56 Antilock Brake System BATT
