11/2009
Page 69
BMW 535i
BMW 550i
Body
No of doors/seats
4 / 5 4 / 5
Length/width/height (unladen) mm
4899 / 1860 / 1464 4899 / 1860 / 1464
Wheelbase mm
2968 2968
Track, front/rear mm
1600 / 1627 1600 / 1627
Ground clearance mm
141 141
Turning circle m
11.95 11.95
Tank capacity app ltr
70 70
Cooling system incl heater ltr
9.3 11,4
Engine oil
1)
ltr
6.5 8,5
Weight, unladen, to DIN/EU kg
1685 / 1760
(1700 / 1775)
1830 / 1905
Max load to DIN kg
610 600
Max permissible kg
2295 (2310) 2430
Max axle load, front/rear kg
1100 / 1275 1195 / 1310
Max trailer load (12%),
braked/unbraked
kg
2000 / 750 2000 / 750
Max roofload/max towbar dwnl kg
100/90 100/90
Luggage comp capacity ltr
520 520
Air resistance Cd x A
0.29 x 2.35 0.30 x 2.35
Power Unit
Config/No of cyls/valves
Strai
g
ht-six / 4 V90 / 8 / 4
Engine technology
BMW TwinPower Turbo,
direct fuel in
j
ection
(Hi
g
h Precision In
j
ection),
fully-
v
ariable valve control
(VALVETRONIC)
BMW TwinPower Turbo,
direct fuel in
j
ection
(High Precision Injection)
Capacity, effective cc
2979 4395
Stroke / bore mm
89.6 / 84.0 88,3 / 89,0
Compression ratio :1
10.2 10.0
Fuel grade
Min RON 91 min RON 91
Max output
kW/hp
225 / 306 300 / 407
at
rpm
5800 5500-6400
Max torque Nm/lb-ft
400/295 600/442
at
rpm
1200-5000 1750-4500
Electrical System
Battery/installation Ah/–
80 (90) / lu
gg
a
g
e comp 90 / lu
gg
a
g
e comp
Alternator A/W
170 / 2380 210 / 2940
Driving Dynamics and Safety
Suspension, front
Double track control arm axle with separate lower track arm level, aluminium,
small steering roll radius, anti-dive
Suspension, rear
Integral-V multi-arm axle, aluminium, with steering function, anti-squat and
anti-dive, double acoustic separation
Brakes, front
Single-piston aluminium swing-calliper disc brakes in frame structure
Diameter mm
348 x 36 / inner-vented
374 x 36 / inner-vented
Brakes, rear
Single-piston swing-calliper disc brakes
Diameter mm
345 x 24 / inner-vented
345 x 24 / inner-vented
Driving stability systems
Standard: DSC incl ABS and DTC D
y
namic Traction Control, CBC Cornerin
g
Brake Control, DBC Dynamic Brake Control, Dry Braking function, Fading
Compensation, Start-Off Assistant; optional: Adaptive Drive
Safety equipment
Standard: airba
g
s for driver and front passen
g
er, side airba
g
s
f
or driver
and front passenger, head airbags for front and rear seats, three-point
inertia-reel belts on all seats with belt stopper, belt tightener and belt force
limiter at the front, crash-activated headrests at the front, crash sensors,
Tyre Defect Indicator
Steering
Electric Power Steering (EPS) with Servotronic;
optional: Integral Active Steering
Steering transmission, overall :1
17.1
17.1
Tyres, front/rear
225/55 R17 97
W
245/45 R18 96Y RSC
Rims, front/rear
8J x 17 light-alloy
8J x 18 light-alloy
BMW 535i Sedan,
BMW 550i Sedan.
