TRANSMITTER OPERATION:
Transmitter
Button
System Function Remark
Lock Doors & Arm System
Panic function Press and Hold for 3 seconds
Car Locator Under armed mode
-
Arm and Delete The 2 Stage Shock
Sensor
Press twice within 3 seconds
+
Silent Arming / Disarming Ignition in "off" position.
Unlock Doors & Disarm System
-
Two Steps Door Unlock & Disarm
System
Press twice within 3 seconds.
Trunk Release (Channel 2) Press and Hold for 2 seconds
-
Passive Arming By-pass While the system Disarmed.
Silent Arming / Disarming or 3
rd
ch
II
Switching code For 2nd Car
Operation.
For regular remote transmitter Only
ACTIVE ARMING – LOCK & ARM:
1. Press
button on transmitter.
2. The siren will chirp once and parking light will flash once indicating that the system is now
armed. The vehicle doors will lock upon arming when interfaced with the security system.
Note: Defective sensor reminder: If the siren sounds 3 chirps, then you have left a door,
trunk, or hood lid ajar.
SILENT ARMING / DISARMING: Press the
button on the transmitter to arm or disarm
your security system with no chirp sound heard; arm / disarm confirmation will be through the
vehicles parking lights only.
SHOCK SENSOR / OPTIONAL SENSOR BY-PASS: Press the
button on the transmitter
twice within 3 seconds will arm the security system, by-pass the shock sensor or the optional
sensor connected to 4 pin plug. The system will chirp one additional time to confirm the
sensor bypass mode was activated. The sensor bypass feature is programmed to activate for
one arming cycle only. The security system will return to normal operation during the next
arming cycle.
PASSIVE ARMING:
Active arming / disarming is controlling your security system via the remote transmitter. This
security system is equipped with an optional Passive Arming feature, which allows the
security system to arm 30 seconds after the last door is closed. Operation is as follows.
1. Turn the ignition to the “OFF” position and exit the vehicle. After all entrances are closed,
the security system LED will flash fast for 30 seconds. If you reopen any door / hood /
trunk, the security system LED will stop flashing. It will begin flashing again once all vehicle
entrances are closed.
2. After 30-second timer has elapsed, the security system will automatically “ARM”. The siren
will chirp [1] time and the parking lights will flash [1] time.
