August, 2005
RS-2 USA 3
E. TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been removed from the ignition. This feature is useful
for occasions when you wish to exit and lock the vehicle for short periods of time, but would like to leave the engine
running and the climate control on.
1.Before turning off the engine, Place the vehicle in “Park”; take your foot off the brake pedal; press the transmitter
button twice and the LED indicator will flash 3 times to confirm enter.
2. Turn the ignition key to the “OFF” position and remove the key. (The engine will stay running.)
3. The engine will run until the pre-programmed time has elapsed or one of the shutdown inputs is received.
F. TIMER START:
This unit can be programmed to start and run the engine every 3 hours. The engine will run for the programmed run time
and then shut down.
IMPORTANT: Timer Start should be used only in open areas. You should never start and run the vehicle in on enclosed
space as a garage or carport.
3 hours timer start: This feature is design for an extreme cold climate usage. The system will auto start the vehicle
every 3 hours, to prevent extremely difficult cold start problems. A MAXIMUM OF SIX CYCLES CAN OCCUR.
ENTER:
1. Press the transmitter button twice to remote start the vehicle. As soon as the vehicle is running and the parking
lights have turned on or flashing.
2. Immediately depress the and button together at the same time, within 2 seconds
3. Quickly press the button. The parking light will flash (3) times. The horn (if installed) chirps (3) times. The vehicle
is now programmed to start every (3) hours.
4. Press the brake pedal to stop the vehicle running.
Exit the timer start:
Timer start can be exited manually as follows:
1. Make sure the remote start system is not operating the engine.
2. Turn the ignition “ON”. The parking light will flash (4) times. The horn (if installed) chirps (4) times.
Or
1. Press the transmitter button twice to remote start the vehicle. As soon as the vehicle is running and the
parking lights have turned on or flashing.
2. Immediately depress the and button together at the same time; then press and hold button for 2 seconds.
The parking lights will flash (4) times. The horn (if installed) will chirp (4) times. The vehicle is no longer programmed
to start automatically.
G. SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the engine will not start or will shut down
immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position. (If installed)
4. Engine is over-revved. {“Tachometer checking type” only}
5. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
6. Press the transmitter button.
7. The vehicle refused to start running after {3} unsuccessful attempts.
8. If your remote start does not start the vehicle after 3 attempts, please take your vehicle
back to your installing
dealer for troubleshooting.
H. DISABLING THE REMOTE START SYSTEM: (If installed)
This feature allows your system’s remote start unit to be temporarily disabled to prevent the vehicle from being remote
started accidentally. This feature is useful if the vehicle is being serviced or stored in an enclosed area. To disable the
remote start, move the (optional) remote start enable toggle switch to the OFF position.
