Technical Data – Audi A4 Avant 3.0 TDI quattro
Program for Germany - Status: May 2009
Model
Audi A4 Avant 3.0 TDI quattro
Engine / electronics
Engine type
6-cylinder diesel engine with VTG turbocharger, DOHC; TDI
direct injection
Valve gear / number of valves per cylinder Roller cam followers with hydraulic valve play compensation / 4
Displacement in cc / bore x stroke in mm / compression 2967 / 83.0 x 91.4 / 16.8
Max. power output in kW (hp) / at rpm 176 (240) / 4000 – 4400
Max. torque in Nm (lb-ft) / at rpm 500 (368.78) / 1500 – 3000
Engine management / mixture preparation Common rail injection system, 1800 bar with piezo injectors, direct injection with
eight-hole nozzles, VTG turbocharger with intercooler; swirl and tangential
intake ports, regulated swirl port; Bosch EDC; rail-pressure control and multiple
injection, charge pressure and EGR control
Exhaust emission control Air-gap insulated exhaust manifold, water-cooled exhaust gas recirculation,
close-coupled oxidizing catalytic converter, close-coupled, maintenance-free
diesel particulate filter
Emissions class EU 5
Alternator in A / battery in A/Ah 140 / 520 / 110
Drivetrain / transmission
Drive type quattro permanent all-wheel drive with self-locking center differential, ESP
Clutch Hydraulically operated dual-plate dry
clutch with asbestos-free and lead-
free linings, dual-mass flywheel
Hydraulic torque converter with lock-up
clutch
Transmission type 6-speed manual, synchromesh on all
gears
6-speed tiptronic with DSP and sport
program
Gear ratio in 1st gear / 2nd gear 3.667 / 1.950 4.171 / 2.340
Gear ratio in 3rd gear / 4th gear 1.207 / 0.848 1.521 / 1.143
Gear ratio in 5th gear / 6th gear 0.651 / 0.538 0.867 / 0.691
Reverse gear / final drive ratio 3.222 / 3.682 3.403 / 2.878
Suspension / steering / brakes
Front suspension Five-link front suspension, upper and lower wishbones, tubular anti-roll bar
Rear suspension Independent-wheel, trapezoidal-link rear suspension with resiliently mounted
subframe, anti-roll bar
Steering / steering ratio / turning circle in meters (D102) (feet) Maintenance-free rack-and-pinion steering with power assistance /
16.3 / 11.5 (37.73)
Brake system Dual-circuit brake system with diagonal split, ABS/EBD and ESP with brake
assist; tandem brake booster; front: ventilated disks / rear: disks
Wheels / tires 7.5J x 16 cast aluminum wheels / 225/55 R 16
Performance / consumption / acoustics
Top speed in km/h (mph) 250 (155.34) 250 (155.34)
Acceleration, 0-100 km/h (0-62.14 mph) in sec 6.3 6.3
Fuel type Diesel, according to EN 590
Fuel consumption: city / highway / combined, l/100 km (US
mpg)
8.8 / 5.5 / 6.8 (26.73 / 42.77 / 34.59) 9.0 / 6.1 / 7.2 (26.13 / 38.56 / 32.67)
CO
2
emissions: city / highway / combined, g/km (g/mile) 231 / 144 / 176 (371.76 / 231.75 /
283.24)
234 / 159 / 186 (376.59 / 255.89 /
299.34)
Idling / drive-past exterior noise level in dB (A) 75 / 74 75 / 74
Servicing / guarantee (Germany)
LongLife Service
Per service indicator, depending on operating conditions (max. 2 years)
1)
Vehicle / paint / rust perforation guarantee 2 years with unlimited mileage / 3 years / 12 years
Weights / loads
Unladen weight in kg / gross weight limit in kg (pounds) 1695 / 2265 (3736.84 / 4993.47) 1735 / 2305 (3825.02 / 5081.66)
Axle load limit at front / rear in kg (pounds) 1180 / 1205 (2601.45 / 2656.57) 1215 / 1210 (2678.62 / 2667.59)
Trailer load limit, unbraked in kg (pounds) 750 (1653.47)
Trailer load limit on 8% / 12% gradient, braked in kg (pounds) 2100 / 1900 (4629.71 / 4188.78)
Roof load limit in kg / permissible nose weight in kg (pounds) 90 / 80 (198.42 / 176.37)
Capacities
Cooling system capacity (incl. heating) in liters (US gallons) 9.0 (2.38)
Engine oil capacity (including filter) in liters (US quarts) 7.4 (7.82)
Fuel tank capacity in liters (US gallons) 64 (16.91)
Body / dimensions
2)
Body type Galvanized, unitary steel body, crumple zones at front and rear
Number of doors / seats 5 doors with additional side protection / 5
Drag coefficient Cd / frontal area A in m
2
(square feet) 0.325 / 2.20 (23.68)
Length (L103)/width excluding mirrors (W103)/height (H101-M) 4703 / 1826 / 1436 (15.43 / 5.99 / 4.71) in mm (feet)
Wheelbase (L101) / track at front/rear (W101-1/W101-2) 2808 / 1564 / 1551 in mm (feet)
Height of loading lip in mm (H196) (feet) 631 (9.21 / 5.13 / 5.09)
Luggage capacity in liters (cubic feet), according to VDA block
method V211-2 (V214-1)
490 (17.30) (loaded up to roof with rear seat folded down: 1430 (50.50))
1) depending on driving style and operating conditions 2) details of dimensions with vehicle unladen weight
