Owners Guide
Remote Start
Reservation Mode - MANUAL TRANS MODELS ONLY
Remote Stop
Idle Mode
1. Press & release the button.
2. The Park lights will flash one time and the horn(optional) will honk one time.
3. When the vehicle has started, the system will flash the park lights four times and then
remain “on” while the vehicle is running.
4. The vehicle will continue to run for the programmed runtime. (normally 15 minutes).
EXTEND RUNTIME
1. Press & release the button while the vehicle is running.
2. The system will respond with one park light flash and one horn honk (optional) to
confirm Extended Runtime. The system will reset the run time, (normally 15 minutes).
3 sec.
1. Press and hold the button for three seconds. The remote starter will shut down.
2. The park lights will flash two times and the horn(optional) will honk two times.
Note: Pressing the brake pedal or opening hood will also stop the vehicle.
1. While the vehicle is running with key, press the button.
2. The park lights will turn on and the horn(optional) will honk once.
3. Turn the ignition key “off” and the vehicle will continue to run.
4. Exit the vehicle and leave it running safely without the keys in the ignition. Lock the
door while the vehicle is left running.
While
running
1st
2nd-6 sec
REMOTE STARTER FEATURES
3
1. While the vehicle is running, apply the park brake then press & release the brake pedal.
2. The park lights will flash to confirm that reservation mode has been activated.
3. Remove key from ignition, and exit the vehicle. (vehicle will remain running)
4. The vehicle will shut off when the door is closed.
(If your vehicle has a delay dome-light, the vehicle may run until the dome-light turns off)
5) The vehicle is now in Reservation Mode and may be remote started
NOTE: Opening a door at this point will cancel the Reservation Mode.
Diagnostics
PARK LIGHTS STATUS LED DIAGNOSTIC CODE
3 Flashes Series of 3 Flashes Door Opened “M” Models
4 Slow Flashes Series of 4 Flashes Not in Reservation Mode “M” units
5 Flashes Series of 5 Flashes Hood Pin Grounded (Open)
6 Flashes Series of 6 Flashes Brake Pedal Shutdown
7 Flashes Series of 7 Flashes Tach Lock-Out
8 Flashes Series of 8 Flashes 3 Start Attempts with no start
Timer / Optional Temp Start
1.Press & release the # button, then press and hold the button for six seconds, until the
parking lights turn “on”.
2. While the parking lights are “on” the start cycle can be selected.
1 hour cycle or 0C Press LOCK button 1 flash
2 hour cycle or -5C Press UNLOCK button 2 flashes
3 hour cycle or -15c Press button 3 flashes
4 hour cycle or -25c Press button 4 flashes
3. System will start vehicle at selected cycle for up to 24 hours.
4. The temp start must have the temp sensor installed and will only trigger 1 time each 2
hours if the sensor is not installed the unit will activate the timer mode.
TO CANCEL COLD START MODE
1. Press & release the # button, then press and hold the button for four seconds.
2. The park lights will flash and the siren will chirp twice.
#
