Chapter 1: Overview 1-9
Heading and Position
Data
Heading and Position
Data
Heading and Position Data
Full functionality of the radar/chartplotter is achieved when it is part of an
integrated system with other equipment (in addition to another
hsb
2
unit)
connected via SeaTalk or NMEA 0183. Data from this equipment including
position and heading is shown on the display and is used in calculations.
Details on connecting other equipment are given in Chapter 8.
Providing Heading Data forMARPA
The performance of MARPA is dependent on the quality of your heading
sensor. It is important that both the heading sensor and the radar scanner
(bearing alignment) are correctly calibrated. Refer to the appropriate heading
sensor and radar scanner handbooks for calibration details. The better the
accuracy of your heading data, the better the performance of MARPA.
Agyrocompassprovidesthebestperformanceinallconditions.Alternatively
you could use a fluxgate compass with rate gyro stabilization.
MARPA requires heading data to be frequently updated (we recommend a
dataoutput rateof greaterthan 8Hz); headingdata mustthereforebe provided
to the display on NMEA.
In multiple-display systems, heading must be connected, via NMEA, to each
display that will be used for MARPA.
We recommend the Pathfinder Smart Heading System (which includes the
Gyro Plus 2 unit). Good results are also obtained with a Raymarine autopilot
system incorporating a 150G or 400G Course Computer with internal rate
gyro.
Other heading sensors connected on NMEA may provide satisfactory results
in reasonablesea states.However,in unsettled conditions arate gyrocompass
is advisable.
Contact Raymarine Customer Services or your authorized Raymarine dealer
for additional information. For specific configuration details with the
Raymarine course computer refer to Appendix E. If you are using a suitable
third party heading sensor, refer to its documentation for installation and
calibration details.
