EN
6
Temperature resolution : 0.1°C (0.2°F)
Remote Temperature measurement
Displayed OUT temperature range : -50.0°C to +70.0°C
(-58.0°F to 158.0°F)
Proposed operating range : -5.0°C to +50.0°C
(23.0°F to 122.0°F)
Temperature resolution : 0.1°C (0.2°F)
Remote unit
Displayed range : -50.0°C to +70.0°C
(-58.0°F to 158.0°F)
Proposed operating range : -20.0°C to +60.0°C
(-4.0°F to 140.0°F)
Temperature resolution : 0.1°C (0.2°F)
RF Transmission Frequency : 433 MHz
No. of Remote unit : one
RF Transmission Range : Maximum 30 meters
Temperature sensing cycle : around 30 seconds
Relative Humidity Measurement
Indoor relative humidity measurement ranging from 25%RH to
95%RH
Barometric Pressure Measurement
Pressure measuring range : 795 to 1050 mb/ hPa
(23.48 to 31.01 inHg)
Pressure sampling cycle : 15 minutes
Moon Phase Functions
Moon Phase Scanner Range : From 1990 to 2089
Radio Controlled Clock
- Maintime set and synchronized by Radio Signal DCF77 for
Continental/ Central Europe
- user selectable 12 or 24h display with hh : mm ss
- Date Format : Day-Month-Year or Month-Day-Year
- Day of week selectable in 5 language (E, F, D, I, Sp )
- 2-minute crescendo alarm
Power
Main unit : use 4 pcs UM-3 or “AA”
1.5V alkaline batteries
Remote sensing unit : use 2 pcs UM-4 or “AAA”
1.5V alkaline batteries
Weight
Main unit : 306 gm
Remote sensing unit : 100 gm
Dimension
Main unit : 182(L) x 133(W) x 28(T)
mm
Remote sensing unit : 92(L) x 60(W) x 21(T) mm
HOW TO RESET THE UNIT
The RESET button allows you to return all settings to its factory
values. The button is required only when the unit is not operating in
a favorable way, such as in the rare case of a malfunction.
The RESET button is located inside the battery compartment door.
To use the button,
1. Lift open the battery compartment door.
2. Press the button with a blunt stylus.
3. Replace the battery compartment door.
PRECAUTIONS
This unit is engineered to give you years of satisfactory service if
you handle it carefully. Here are a few precautions:
1. Do not immerse the unit in water. If you spill liquid over it, dry
it immediately with a soft, lint-free cloth.
2. Do not clean the unit with abrasive or corrosive materials. They
may scratch the plastic parts and corrode the electronic circuit.
3. Do not subject the unit to excessive force, shock, dust, tempera-
ture or humidity, which may result in malfunction, shorter
electronic life span, damaged battery and distorted parts.
4. Do not tamper with the unit’s internal components. Doing so
will invalidate the warranty on the unit and may cause unnecessary
damage. The unit contains no user-serviceable parts.
5. Only use fresh batteries as specified in the user’s instructions.
Do not mix new and old batteries as the old ones may leak.
6. Always read the user’s instructions thoroughly before operating
the unit.
TIME ZONE AND OFFSET TABLE
SPECIFICATIONS
Temperature Measurement
Main unit
Indoor Temperature measurement
Displayed IN temperature range : -50.0°C to +70.0°C
(-58.0°F to 158.0°F)
Proposed operating range : -5.0°C to +50.0°C
(23.0°F to 122.0°F)
BAR928-E R1 OP 8/21/04, 11:54 PM6
