CABLE FREE WEATHER STATION
MODEL: BAR928
USER’S MANUAL
INTRODUCTION
Congratulations on purchasing the BAR928 Top Weather Station.
The BAR928 is an all-in-one clock and weather device. RF- control-
led, it can automatically synchronize its current time and date when
it is brought within an approximate 1500km radius of the radio
signal generated from Frankfurt, Germany (DCF77).
The BAR928 does weather forecasts and tells temperatures, indoors
and outdoors. It also shows the trend of changes plus the recorded
maximum and minimum temperatures. A remote thermo sensor is
included with the unit.
Apart from temperature, the BAR928 shows the indoor relative
humidity and rates the comfort level. It also retains the maximum
and minimum relative humidity readings.
The built-in barometer enables the BAR928 to display the atmos-
pheric pressure with user-selectable altitude adjustment. A bar
graph will show the pressure trend of the last 24 hours.
What is more, the BAR928 is equipped with a moon phase scanner,
which lets you check the moon phase of any day between 1990 and
2089.
Other features include a HiGlo backlight, daily crescendo alarm
with eight-minute snooze function, and extra-large display.
No wire installation is required between the main and remote units.
As the BAR928 operates at 433MHz, it can be used in the U.S. and
most places in Continental Europe.
MAIN FEATURES: MAIN UNIT
A
RADIO RECEPTION SIGNAL
Indicates the condition of radio reception
B
SNOOZE/LIGHT BUTTON
Activates the snooze function when an alarm goes off or turn
on the backlight for five seconds
C
MODE WINDOW
Displays the current time and date
D
ALARM ON ICON
Appears when the alarm is activated
E
ALARM ICON
Appears when the alarm time is displayed
F
MAIN UNIT BATTERY LOW (BATT) INDICATOR
Lights up and blinks when the batteries of the main unit are
running dry
G
REMOTE UNIT BATTERY LOW (BATT) INDICATOR
Lights up and blinks when the batteries of the remote unit are
running dry
H
WEATHER FORECAST WINDOW
Displays the weather pattern
I
TEMPERATURE WINDOW
Shows the current temperature or the maximum or minimum
recorded temperature
J
IN/OUT-REMOTE INDICATOR
Indicates if the current temperature is displayed as indoors or
outdoor-remote
K
TEMPERATURE TREND ARROWS
Indicates the trend of temperature changes
L
°C/°F SLIDE SWITCH
Selects between Centigrade (
°C) and Fahrenheit (°F) display
M
RELATIVE HUMIDITY WINDOW
Displays the indoor relative humidity
N
COMFORT INDICATOR
Indicates the comfort level of the indoor relative humidity
O
ATMOSPHERIC PRESSURE CHART
Shows the atmospheric pressure trend chart of the last 24 hours
P
ATMOSPHERIC PRESSURE WINDOW
Displays the current atmospheric pressure
Q
PRESSURE HISTORY INDICATOR
Indicates the pressure history of previous hours
