79
These figures show menu sequence (from left to right) for selecting a Navionics
chart for the South Chesapeake Bay area.
3. To turn off a Navionics chart, From the Map Page, press MENU| to
MAP DATA|ENT| to MAP CHOICE|ENT. Use or to select LOWRANCE, then
press
ENT|EXIT|EXIT.
Port Information
Navionics charts contain Port Services information, represented by anchor
icons on the map display. An example is displayed in the following figure.
To view Port Services information:
1. Use the arrow keys to move the cursor over a Port Services icon.
When selected, a pop-up name box appears.
2. Press
FIND|ENT to display the Port Services Information screen.
The Port Services information screen has two windows. The top window
lists the various service categories. The lower window lists the detailed
services available in each basic category.
Navionics chart showing Port Services icon selected by cursor.
3. To scroll through the Service Categories window: press ENT then use
or to see the types of services available. As you highlight a different
category, the list in the lower window changes. To return to the Map
Page, press
EXIT|EXIT.
Port Services
icons
Pop-up
name box
Cursor lines
