Remove all pieces from the Infinium LS box. All
assembly hardware is located in a clear plastic bag
inside the bag containing the control housing pouch.
1. The cuff on the end of the s-handle has been
factory installed. Test its placement by grasping the
black-rubbered s-handle (Figure 1). If the cuff does
not fit comfortably under your forearm, loosen the
nut, remove the nut, bolt and washers, and reposition
the cuff. Reinsert the bolt and washers, and tighten
the nut.
2. Remove the black stem piece that has been tele-
scoped into the silver stem (Figure 2). Insert the end
of the silver stem piece, with the hole 2" from the top,
over the bottom of the black stem at the end of the
s-handle. Significant pressure needs to be applied to
the silver stem in order to insert the bolt (Figure 3).
6
ASSEMBLY
Figure 1
Figure 2
