CAUTION! A few vehicles
(including some Porsches) have
windshields with a soft anti-lacera-
tive coating on the inside surface.
Use of suction cups will perma-
nently mar this coating. Consult
your dealership or the vehicle
owner’s manual to determine if
your windshield has this coating.
7
Windshield Mount
Facing Down Facing Up
When installed and adjusted properly,
the back top edge of PASSPORT should
rest solidly against your windshield.
User’s Tip
You can leave the EasyMount bracket in
place on your windshield, and easily
remove PASSPORT by pressing the adjust-
ment button and sliding PASSPORT off the
mount. Again, be sure to position the
bracket where it won’t present a hazard in
the event of an accident. Additional
mounts are available.
Level mounting
Windshield Mount
PASSPORT’s EasyMount windshield
bracket is designed for unobtrusive and
hassle-free mounting.
1 Depress the adjustment button on the
top of PASSPORT (by the word ESCORT)
and slide the EasyMount bracket into the
slot until it is locked into the position
which best fits the angle of your wind-
shield (there are four settings available).
For extremely horizontal or extremely
sloped windshields, the EasyMount
bracket can be bent.
To ensure that the suction cups
adhere to the windshield firmly, be sure to
keep both your windshield and the
suction cups clean.
2 To adjust PASSPORT on your wind-
shield, use the EasyMount adjustment
button located on the top of the
PASSPORT, and slide PASSPORT forward
or backward to obtain a level horizontal
position.
