Reference Manual
00809-0700-4530, Rev AA
Section 5: Troubleshooting Procedures
September 2013
Troubleshooting procedures
Figure 5-7. Surface peak is below the surface threshold
Figure 5-8. Surface peak is above the surface threshold
Amplitude
Distance
Surface threshold
(ATC)
Rosemount 5301
The surface peak is undetected
because it is below the surface
threshold
Amplitude
Distance
Surface threshold
(ATC)
Rosemount 5301
The surface peak is detected
because it is above the surface
threshold
