Troubleshooting procedures
5.4.1 Echo curve constituents
Figure 5-2. Echo curve presentation in RRM
Amplitude
Distance
Reference
peak
Surface
peak
UNZ Surface
threshold
Reference peak
Surface peak
Amplitude
Distance
As presented in RRM
