Ford Throttle Lever Adapter
Catalog # 1483
Instructions
Return Spring
10-32 Bolt, Lockwasher & Nut
Throttle Lever Adapter
Kick-down Lever Return Spring Bracket
1/4-20 Bolt,
Lockwasher & Nut
Installation of Adapter:
• Follow the PERFORMER SERIES CARBURETOR INSTALLATION
INSTRUCTION sheet included with the carburetor. During step #1 of
the “PREPARATION OF CARBURETOR FOR INSTALLATION” section you
should attach the Throttle Lever Adapter to the existing throttle lever
using the appropriate bolts, lockwashers, and nuts making sure the
adapter is secured properly.
• Continue installing the carburetor according to the PERFORMER
SERIES CARBURETOR INSTALLATION INSTRUCTIONS. While
performing step #2 of the “INSTALLATION OF CARBURETOR,” install
the kick-down lever return spring bracket before tightening the nuts.
• Continue to install the carburetor using the PERFORMER SERIES
CARBURETOR INSTALLATION INSTRUCTIONS.
The #1483 Ford Throttle Lever Kit will allow you to connect 1967 and
newer Ford automatic transmission kick-down linkage to the Edelbrock
Performer Series Carburetor (
Will not work with AOD
). If your vehicle
has cable-type throttle linkage, you may also need the appropriate
Edelbrock Throttle Cable Plate Kit. Please study these instructions
carefully before installing your Ford Throttle Lever Adapter Kit. If you
have any questions, do not hesitate to contact our Technical Hotline at:
1-800-416-8628.
Kit Contents:
1—Throttle Lever Adapter 1—10-32 Bolt
1—10-32 Lockwasher 1—10-32 Nut
1—Kick-down Lever Return 1—1/4-20 Bolt
1—1/4-20 Lockwasher Spring Bracket 1—1/4-20 Nut
Catalog #1483
Rev. 1/08 AJ/mc
©2008 Edelbrock Corp.
Brochure #63-1483
®
