Chrysler Throttle Lever
Adapter Kit
Catalog # 1481
Installation Instructions
10-32 Bolt, Lockwasher & Nut
Throttle Lever
Throttle Lever Adapter
1/4-20 Bolt,
Lockwasher
& Nut
Kit Contents:
1 Throttle Lever Adapter 1 10-32 Bolt 1 10-32 Nut 1 10-32
Lockwasher 1 1/4-20 Bolt 1 1/4-20 Nut 1 1/4 Lockwasher
Installation of Adapter
A. Follow the PERFORMER SERIES CARBURETOR INSTALLATION INSTRUCTIONS included with
the carburetor. During step 1 of the PREPA R ATION OF CARBURETOR FOR INSTALLATION sec-
tion you should att ach the Throttle Lever Adapter to the existing throttle lever using the appropriate
bolts, lockwashers, and nut s making sure the adapter is secured properly.
B. Continue to inst all the carburetor using the PERFORMER SERIES CARBURETOR INSTALLATION
INSTRUCTIONS.
' 1998 Edelbrock Corp. REV 6/98
The #1481 Chrysler Throttle Lever Kit will allow you to connect Chrysler throttle linkages to the
Edelbrock Performer Series Carburetor. Please study these instructions carefully before inst alling your
Throttle Lever Adapter Kit.
If you have any questions or problems, do not hesit ate to cont act our Technical Hotline at: 1-800-416-
8628.
