Crimestopper Security Products EZ-90 Remote Starter User Manual



TABLE OF CONTENTS
Pre-Installation Considerations……….………...……...……………………………………………………………….……2
Cautions & Warnings…….…………...….……..…..……………………………………………………………….…..……3
Wiring……..…………………………....……………………………………………………………………………….…….3-7
Wiring High-Current Connector…….………………...………………………………………………………………….....8-9
Power Door Lock Wiring...………………………………………….…………….……..…………...……………………10-11
Smart Tachless, Tach Reference, Tach Finder, & Timed Crank Modes…………………..…..………...…...………12-15
Diesel Glow Plug Delay..………………….…………………………………...……………………...…..…………………16
Options Programming ………..……………………….…………………………………...……………..…………………16-
21
Transmitter / Transceiver Programming……………………….…………………….……………..………...………...….22
2 Vehicle Operation.……………………………….……………………………………...…………………….……………23
Troubleshooting “Before You Call” Section……………..…………………………..………………….………….………24
Jumper Pin, Antenna, & System Diagrams…………………………………………………………..………….….……25-27
PRE-INSTALLATION CONSIDERATIONS
BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS,
ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY).
PLAN OUT YOUR INSTALLATION and determine most suitable locations for all components to be placed. These
components include: the module itself, valet/program button, possible relays, and antenna/receiver (EZ-
90/777TW1/TW2/FM only, EZ-91 model does not include its own antenna or remotes.) Allow enough wire to create a
service loop with strain relief, should servicing be required. This will also allow easier access and mounting.
DAMAGE to the EZEE unit resulting from incorrect installation or failure to follow guidelines stated in this book will not
be covered under warranty and will be subject to repair or replacement charges.
USE A VOLT/OHM METER to test and locate all connections. Test Lights can damage a vehicle’s computer systems.
ADDITIONAL PARTS, which are not included with this unit, may be needed for your particular vehicle. . These items
may include extra relays or Anti-Theft System Bypass modules.
2
